Harley-Davidson
HARLEY-DAVIDSON 2025 LOW RIDER™ S 117 FXLRS
Thanks for your interest in Harley-Davidson. Please provide your details below and a member of our team will be in touch soon.
This brand is sold at the following dealerships:
Please contact us for availability of specific models.
Advertised ‘Ride Away Price’*
Advertised ‘Ride Away Price’ includes on road costs and is subject to change. Overseas models may be shown with accessories that are not standard fitment. Fraser Motorcycles reserves the right to vary colours, specifications & pricing at any time.REAR SUSPENSION
A tall monoshock kicks up the rear end, giving you extra cornering clearance when you're pushing the limits.
MILWAUKEE-EIGHT™ 117 H.O ENGINE
High-output Milwaukee-Eight® 117 engine is tuned to deliver peak power in the upper rev range and entice riders who want to push their bike to the limit.
TWO- INTO-ONE EXHAUST
Lightweight, blacked-out exhaust system is sleek and compact with high-flowing performance.
HAND CONTROLS
Updated hand controls accommodate Rider Safety Enhancements like Cruise Control and Traction Control, while an adjustable brake lever lets riders tune ergonomics to their preferences
DETAILED SPECS
DIMENSIONS
LENGTH | 2,360 mm |
SEAT HEIGHT, UNLADEN | 715 mm |
GROUND CLEARANCE | 145 mm |
RAKE | 28 |
TRAIL | 145 mm |
WHEELBASE | 1,615 mm |
TYRES, FRONT SPECIFICATION | 110/90B19,62H,BW |
TYRES, REAR SPECIFICATION | 180/70B16,77H,BW |
TYRE, TYPE | Michelin Scorcher "31" front and rear |
FUEL CAPACITY | 18.9 l |
OIL CAPACITY (W/FILTER) | 4.7 l |
WEIGHT, AS SHIPPED | 292 kg |
WEIGHT, IN RUNNING ORDER | 304 kg |
ENGINE
ENGINE | Milwaukee-Eight® 117 High-Output |
BORE | 103.5 mm |
STROKE | 114.3 mm |
DISPLACEMENT | 1,923 cc |
COMPRESSION RATIO | 10.3:1 |
FUEL SYSTEM | Electronic Sequential Port Fuel Injection (ESPFI) |
EXHAUST | 2-into-1; catalyst in header |
PERFORMANCE
ENGINE TORQUE TESTING METHOD | EC 134/2014 |
ENGINE TORQUE | 173 Nm |
ENGINE TORQUE (RPM) | 4000 |
HORSEPOWER | 114 HP / 85 kW @ 5020 rpm |
LEAN ANGLE, RIGHT (DEG.) | 31.3 |
LEAN ANGLE, LEFT (DEG.) | 31.3 |
FUEL ECONOMY TESTING METHOD | EU 134/2014 |
FUEL ECONOMY | 5.6 l/100 km |
DRIVE TRAIN
PRIMARY DRIVE | Chain, 34/46 ratio |
GEAR RATIOS (OVERALL) 1ST | 9.311 |
GEAR RATIOS (OVERALL) 2ND | 6.454 |
GEAR RATIOS (OVERALL) 3RD | 4.793 |
GEAR RATIOS (OVERALL) 4TH | 3.882 |
GEAR RATIOS (OVERALL) 5TH | 3.307 |
GEAR RATIOS (OVERALL) 6TH | 2.79 |
CHASSIS
FRONT FORK | Single cartridge 43 mm inverted with aluminum fork triple clamps; triple rate spring |
REAR SHOCKS |
Hidden, free piston, coil-over monoshock; 56 mm stroke; hydraulic preload adjustment |
WHEELS, FRONT TYPE | Black, Radiate Cast Aluminium |
WHEELS, REAR TYPE | Black, Radiate Cast Aluminium |
BRAKES, ROTOR TYPE | Front and rear black, Split 7-spoke floating rotors |
BRAKES, CALIPER TYPE | 4-piston fixed front and 2-piston floating rear |
ELECTRIC
LIGHTS (AS PER COUNTRY REGULATION), INDICATOR LAMPS | Headlamp: All LED, low beam, high beam and signature position lamp; Tail/Stop: LED Buffett tail lamp; Front Signal Lights: LED Bullet Turn Signals |
GAUGES |
4-inch analogue speedometer with digital gear, odometer, fuel level, ride modes, heated gear, traction control, ABS, TPMS, cruise control, clock, trip, range and tachometer indication |
RIDER SAFETY ENHANCEMENTS
ANTI-LOCK BRAKE SYSTEM (ABS) |
Included |
TRACTION CONTROL SYSTEM (TCS) | Included |
