Harley-Davidson
Harley-Davidson 2025 X™ 500
Thanks for your interest in Harley-Davidson. Please provide your details below and a member of our team will be in touch soon.
This brand is sold at the following dealerships:
Please contact us for availability of specific models.
Advertised ‘Ride Away Price’*
Advertised ‘Ride Away Price’ includes on road costs and is subject to change. Overseas models may be shown with accessories that are not standard fitment. Fraser Motorcycles reserves the right to vary colours, specifications & pricing at any time.Indicative ‘per week price’**
Key Features
Engine
Rugged and reliable 500cc powertrain, liquid cooled for consistent and optimal performance in all riding situations.
Seat
Seat width and pad thickness are designed to enhance comfort on longer rides.
American Roadster Styling
Inspired by design cues from Harley-Davidson Sportster™ models
Real-world street-riding performance
Lightweight and agile, with an engine tuned for strong mid-range torque.
Riding ergonomics
Mid foot controls and a mid-rise handlebar puts the rider in a centered, comfortable posture on the bike.
Sound of Pleasure
2-into-1 exhaust designed to produce a pleasing low-frequency tone.
Technical Specifications
Technical Specifications
|
|
DIMENSIONS
|
|
Length |
2,135 mm
|
Seat Height, Unladen |
153 mm
|
Seat Height, Unladen |
153 mm
|
Ground Clearance |
24.5
|
Rake |
100.4 mm
|
Trail |
1,485 mm
|
Wheelbase |
Maxxis Supermaxx ST
|
Tyres, Type |
120/70-ZR17/58W
|
Tyres, Front Specification |
160/60-ZR17/69W
|
Tyres, Rear Specification |
13.1 l
|
Fuel Capacity |
3.2 l
|
Oil Capacity (w/filter) |
199 kg
|
Weight, In Running Order |
208 kg
|
ENGINE
|
|
Engine |
Liquid-cooled, Parallel-Twin, 500cc
|
Bore |
69 mm
|
Stroke |
66.8 mm
|
Displacement |
500 cc
|
Compression Ratio |
11.5:1
|
Fuel System |
Electronic Sequential Port Fuel Injection (ESPFI)
|
Exhaust |
2 into 1 short single, 3 catalyst
|
PERFORMANCE
|
|
Engine Torque Testing Method |
GB/T20076-2006, GB/T5363-2008
|
Engine Torque |
46 Nm
|
Engine Torque (rpm) |
6000
|
Horsepower |
47 HP / 35 kW @ 8500 rpm
|
Lean Angle, Right (deg.) |
46.9
|
Lean Angle, Left (deg.) |
49.5
|
Fuel Economy Testing Method |
WMTC
|
Fuel Economy |
4.85 l/100 km
|
CO2 Emissions Testing Method |
WMTC
|
CO2 Emissions |
112 g/km CO2
|
DRIVE TRAIN |
|
Primary Drive |
Chain, 74/38
|
Gear Ratios (overall) 1st |
2.85
|
Gear Ratios (overall) 2nd |
1.95
|
Gear Ratios (overall) 3rd |
1.56
|
Gear Ratios (overall) 4th |
1.33
|
Gear Ratios (overall) 5th |
1.19
|
Gear Ratios (overall) 6th |
1.08
|
CHASSIS |
|
Front Fork |
50mm upside down rebound adjustable
|
Rear Shocks |
Oil and gas separation type, rebound damping adjustable, preload adjustable shock absorber
|
Wheels, Front Type |
Cast aluminium
|
Wheels, Rear Type |
Cast aluminium
|
Brakes, Caliper Type |
Front floating, rear solid
|
Brakes, Rotor Type |
Brakes, Rotor Type
|
ELECTRIC |
|
Lights (as per country regulation), Headlamp, Tail/Stop/Front Signal Lights |
All LED, low beam, high beam and signature position lamp. All LED Tail/Stop, front signal lights and rear turn signals.
|
Gauges |
Combined electronic instrument stepper motor indicating vehicle speed, digital indicates rpm, hour, total trip, two trips (A + B), km/mile indication
|
