Honda
HONDA PIONEER SXS1000-6
This brand is sold at the following dealerships:
Please contact us for availability of specific models.
Advertised ‘Ride Away Price’*
Advertised ‘Ride Away Price’ includes on road costs and is subject to change. Overseas models may be shown with accessories that are not standard fitment. Fraser Motorcycles reserves the right to vary colours, specifications & pricing at any time.HONDA PIONEER SXS1000-6
EOFY SALE NOW ON!
SAVE $3000 AND RECEIVE A FREE EU22i GENERATOR!
You can count on the Pioneer 1000 for all the tough jobs, with smart technology, superior materials, refined engineering and Honda’s well-earned and world-famous reputation for reliability and overall quality. The Pioneer 1000 has a 6-speed state-of-the-art beltless dual clutch transmission (DCT), with manual or fully automatic modes, that is durable, efficient and easy to use, coupled with a purpose-built inline twin-cylinder, Unicam® 999cc engine. The 4WD system has an option for every situation. Don’t want to tear up sensitive surfaces, select Turf Mode. Want to access as much traction as possible, put it in 4WD. Need maximum power at all four wheels, lock the front and rear differentials. And the best part is, you can do it all with a shift of a single lever. And when the jobs are too big to tackle alone you can bring the whole crew.
Low maintenance transmission
Durable, all-gear 6-Speed fully automatic Dual Clutch Transmission (DCT) with manual over-ride mode
Hydraulic assist tilt bed
Makes moving/dumping cargo a breeze
Reliable, hardworking powerhouse
Powerful 999cc liquid-cooled twin-cylinder Unicam® four-stroke engine that can tow over a ton!
Powerful 999cc twin-cylinder engine
The 999 cc liquid-cooled parallel-twin 4-stroke engine has revised valve timing and throttle-body settings, resulting in more high and midrange power, without sacrificing smooth delivery. Acceleration is improved and towing capacity has increased to 1,134kg. The Unicam® design produces significant horsepower and torque, and reduces overall engine size and weight, allowing for a roomier cabin design, lower centre of gravity and improved handling. Longitudinal engine mounting ensures most of the engine’s output is transmitted to the wheels.
Independent front and rear suspensions
Dual A-arm suspension gives you 268mm of travel in the front and 254mm of travel in the rear. Pair that with 345mm (3-seater) or 335mm (5-seater) ground clearance, and you maximize available traction and superior comfort manoeuvring over terrain other side-by-sides would shy away from.
Selectable drive modes
The 4WD system has an option for every situation. If you don’t want to tear up sensitive surfaces, you can select “Turf” mode. Want to access as much traction as possible, put it in “4WD”. Need maximum power at all four wheels, lock the front and rear differentials. And the best part is, you can do it all with a shift of a single lever.
6-speed dual clutch transmission (DCT)
Honda’s exclusive automatic Dual Clutch Transmission provides the durability and efficiency of a conventional manual transmission, but can change gears automatically, upshifting and downshifting without driver input. Two automatic shifting modes allow the driver to tune the driving behaviour of the Pioneer 1000: “Sport” mode is more dynamic, while “Standard” is more relaxed. You also have the option of selecting “Manual” mode and making gear changes via paddle shifters mounted on the steering column.
High and low subtransmissions
With a full 42% gear reduction between High and Low, you get the torque you need in all 6 gears. It comes in handy when driving over difficult terrain, scaling steep hills or towing heavy loads.
Optional Enhancements Include:
· Availability of a high quality sealed and insulated cabin that protects the customer from the environment on Elite variant
· HVAC system that maintains occupant comfort in hot or cold climates
· Smooth comfortable drivability in tough conditions with 1000cc DCT, Throttle by Wire, and availability of intelligent i4WD
· Tow-Haul drive mode that tackles heavy loads.
· Pro-Connect Bed enhances utility integration and usability.
· Bed light allows working in dusk till dawn.
· Variable Speed Limiter (VSL) makes spraying and other low speed tasks easier.
|
Chassis |
|
||
|
Brakes |
|||
|
Brakes (F) |
2x 210mm hydraulic disc |
||
|
Brakes (R) |
2x 210mm hydraulic disc |
||
|
Steering |
|||
|
Power Steering |
STD |
||
|
Suspension |
|||
|
Front Adjustability |
- |
||
|
Front Suspension Type |
Independent double-wishbone |
||
|
Front Wheel Travel (mm) |
268 |
||
|
Rear Adjustability |
n/a |
||
|
Rear Suspension Type |
Independent double-wishbone |
||
|
Rear Wheel Travel (mm) |
254 |
||
|
Dimensions, Weights And Capacities |
|
||
|
Capacities |
|
||
|
Dimensions |
|||
|
Bed Dumping Angle |
n/a |
||
|
Turning Radius (m) |
4.75 |
||
|
Wheelbase (mm) |
2,926 |
||
|
Bed Height (mm) |
n/a |
||
|
Bed Length (mm) |
n/a |
||
|
Bed Width (mm) |
n/a |
||
|
Ground Clearance (mm) |
320 |
||
|
Overall Height (mm) |
1,933 |
||
|
Overall Length (mm) |
3,866 |
||
|
Overall Width (mm) |
1,600 |
||
|
Seat Height (mm) |
850 |
||
|
Weights |
|||
| Bed/Tray Weight Capacity (kg) | 454 | ||
| Kerb Weight (kg) | 878 | ||
| Max Weight Capacity (kg) | 748 | ||
|
Towing Capacity (kg) |
1134 |
||
|
Powertrain |
|
||
|
Engine |
|||
|
Bore & Stroke (mm) |
92 x 75.15 |
||
|
Compression Ratio |
10 : 1 |
||
|
Cylinders |
Inline 2 |
||
|
Displacement (cc) |
999 |
||
|
Engine Type |
Liquid-cooled 4-stroke |
||
|
Fuel System |
Fuel Injection |
||
|
Starter |
Electric |
||
|
Valves |
8 |
||
|
Transmission |
|||
|
Drive Modes |
2WD, 4WD, 4WD Lock, Turf |
||
|
Transmission |
6-speed with reverse; manual and automatic modes |
||
|
Drive |
Shaft |
||
|
Tyres And Wheels |
|
||
|
Tyres |
|||
|
Tyres (F) |
27x9-14 |
||
|
Tyres (R) |
27x11-14 |
||
|
Warranty |
|
||
|
Warranty |
36 months |
||
